GIGABYTE B860M DS3H WIFI6E Micro-ATX Motherboard, LGA 1851, DDR5, PCIe 5.0 - B860M DS3H WIFI6E

• Intel LGA 1851 socket compatible with Intel Core Ultra processors
• Four dual-channel DDR5 DIMM slots supporting up to 256 GB at up to 9066 MHz
• PCIe 5.0 x16 slot with EZ-Latch alongside PCIe 5.0 and PCIe 4.0 M.2 slots
• Built-in Wi-Fi 6E, 2.5GbE LAN and USB 3.2 Gen 2 connectivity
• Hybrid 5+1+2+1 phase VRM with MOSFET heatsinks and M.2 Thermal Guard

This micro-ATX motherboard is built for desktop setups running Intel Core Ultra Series 1 and Series 2 processors on the LGA 1851 socket. Designed for dependable performance in compact cases, it features a hybrid 5+1+2+1 phase VRM alongside dedicated MOSFET and PCH heatsinks to maintain stable system operation.

The board offers four DDR5 DIMM slots accommodating up to 256 GB of memory at speeds up to 9066 MHz. Storage and expansion are handled by high-speed M.2 slots, four SATA III ports with RAID support, and a PCIe 5.0 x16 slot featuring an EZ-Latch design alongside an M.2 Thermal Guard for connected drives.

Integrated networking includes Wi-Fi 6E and a 2.5GbE Ethernet port. External connectivity is rounded out by USB 3.2 Gen 2 Type-A ports, one HDMI 2.1 output, and two DisplayPort 2.1 outputs supporting display resolutions up to 4096 x 2160 pixels.
